SLFE8.3 Series Common Mode Choke with 1500 Vdc Isolation Voltage, Wide Inductance Range 1 mH to 50 mH, and Extended Temperature Range -40°C to +105°C for EMI Filtering

5000
MOQ
SLFE8.3 Series Common Mode Choke with 1500 Vdc Isolation Voltage, Wide Inductance Range 1 mH to 50 mH, and Extended Temperature Range -40°C to +105°C for EMI Filtering
Caratteristiche Galleria Descrizione di prodotto Parla adesso.
Caratteristiche
Specificazioni
Gamma di induttanza: Da 1 mH a 50 mH
Tensione di isolamento: 1500 VCC
Temperatura operativa: Da -40°C a +105°C
Dimensioni: 10×9,5×10,5mm
Frequenza di prova: 1,0 kHz/0,3 V
Informazioni di base
Luogo di origine: Cina
Marca: SHINHOM
Certificazione: RoHS/ISO/UL/CE/IATF16949/CNAS
Numero di modello: SLFE8.3
Documento: SLFE8.3 Series_.pdf
Termini di pagamento e spedizione
Tempi di consegna: 2~8 settimane
Termini di pagamento: L/C, T/T
Descrizione di prodotto
High-Performance Common Mode Choke SLFE8.3 Series for Industrial and Telecom EMI Filtering

Designed for robust EMI suppression in space-constrained applications, the SLFE8.3 Series Common Mode Choke delivers exceptional noise filtering across a wide temperature range. Engineered with a wire-wound construction, this compact choke provides high impedance to common mode noise while maintaining high current ratings and low DCR. With a high isolation voltage of 1500 Vdc and an extended operating temperature range of -40°C to +105°C, it ensures reliable performance in industrial, telecom, and automotive environments.

Key Features
  • Wide Inductance Range: Available from 1 mH to 50 mH to meet diverse filtering requirements
  • High Isolation Voltage: Hi-Pot tested at 1500 Vdc for 3 seconds, ensuring superior safety and system protection
  • Extended Temperature Range: Rated for operation from -40°C to +105°C, making it suitable for harsh environments
  • Compact Footprint: Max dimensions of 10×9.5×10.5 mm for high-density PCB layouts
  • Excellent EMI Suppression: Wire-wound construction provides high impedance to effectively suppress common mode noise in power and signal lines
  • RoHS Compliant: Meets environmental standards for global markets
Electrical Specifications
@25°C
Part Number Inductance (mH) +50%/-30% N1=N2 Test Frequency DCR (Ω) Max IDC (A) Max
SLFE8.3-102Y 1.0 1.0 kHz / 0.3V 0.32 0.3
SLFE8.3-502Y 5.0 1.0 kHz / 0.3V 0.58 0.3
SLFE8.3-103Y 10 1.0 kHz / 0.3V 0.77 0.2
SLFE8.3-153Y 15 1.0 kHz / 0.3V 0.82 0.2
SLFE8.3-203Y 20 1.0 kHz / 0.3V 1.36 0.18
SLFE8.3-253Y 25 1.0 kHz / 0.3V 1.54 0.18
SLFE8.3-303Y 30 1.0 kHz / 0.3V 2.40 0.14
SLFE8.3-353Y 35 1.0 kHz / 0.3V 2.60 0.14
SLFE8.3-403Y 40 1.0 kHz / 0.3V 3.40 0.10
SLFE8.3-503Y 50 1.0 kHz / 0.3V 4.80 0.06
Applications
  • Industrial Equipment: Noise suppression for DC power lines and control systems
  • Telecommunications Infrastructure: EMI filtering for base stations and network devices
  • Automotive Electronics: Common mode noise filtering in infotainment and control units
  • Power Supply Units: Designed for use in power converters and DC-DC converters requiring reliable common mode choke performance
  • Data Communication Systems: Effective noise filtering to ensure signal integrity
